Locker Hinge

109.00

SKU CX 172 Category
  • Dimensions: Crafted to perfection, our toilet cubicles boast standard measurements of 900mm W x 1500mm D x 2000mm H, featuring a spacious door of 600mm W x 1800mm H, ensuring comfort and accessibility.
  • Material Excellence: Embrace durability with solid-grade BWP HDF Panels, designed for high density, fire retardancy, and dimensional stability. Resistant to heat, bacteria, chemicals, scratches, and impact, these panels ensure a lasting investment in quality.
  • Standards Compliant: Compliant with IS-2046 and EN438 standards, our cubicles meet the rigorous requirements of fire retardant BS-476/97 standard, guaranteeing safety and adherence to industry benchmarks.
  • Hardware Fittings: Impeccably designed with stainless steel (Grade 304 & 316) hardware fittings, ensuring longevity and resilience. The top fitting arrangement features an SS finish aluminum powder-coated top rail securely fixed to pilasters, providing stability and support.
  • Sturdy Construction: In areas without brick walls, rely on the robust SS finish aluminum powder-coated L-channel at cubicle corners, connected to the top rail. All screws, including those anchoring the stainless steel adjustable legs, are made of stainless steel (Grade-304), ensuring steadfastness.
  • Adjustable Support: Each pilaster is supported by stainless steel (Grade-316) adjustable feet, anchored to the floor with a 150mm clearance height, delivering both stability and adaptability.
  • Aesthetically Pleasing: The finished product adheres to approved textures, shades, and drawings, adding a touch of sophistication to your restroom space.

Providing and fixing toilet cubicle systems of DEBO/STYLAM make and installed by Supercreations in standard dimensions of 900-1200mm width X 1500mm depth X 2105mm height with a door size of 600mm width X 1830mm height with 12mm thickness. The solid grade Compact Laminate panels made of Phenolic resins under high pressure and temperature having density >1400 kg/m3, including doors, pilasters & intermediate panels, which are resistant to heat, bacteria, chemical, scratch and impact & water immersion through permissible increase on weight will be <0.60~0.8%. Finished product will be as per approved texture, shade & drawing, detailing and developed according to IS-2046 and EN438 standards and as per fire retardant BS-476/97 standard. The product should have Green Guard Certificate. The toilet cubicle setup shall include necessary hardware fittings, made out of stainless steel (Grade-304 & 316), as per manufacturer’s specifications and approved by the engineer.

Hardware fittings consist of:

SS 304 U-channels
SS304 top rail
SS 316 adjustable foot of 150mm
SS 316 indicator lock
SS 316 door knob
SS 316 coat hook

The top fitting arrangement shall comprise of Aluminum Anodized SS finish top rail of 125mm wide fixed to walls by L-Bracket. All screws should be of stainless steel (Grade-304). All pilasters shall be supported by Aluminum Anodized top rail gives suspended floating look with a clearance height of 100mm. The intermediate panel shall be of one continuous panel without any joint. All visible edges shall be chamfered.
